Cellule à aimant mobile MM - Anniversaire 80 ans - sortie 5 mV


JTS-80LB NEW Diamant de remplacement - cantilever aluminium pointe diamant tarif 149€


Aluminum cantilever and diamond-bonded elliptical hands provide high cost performance and powerful sound over a wide range.



Nagaoka JT-80LB

229,00 €Prix
  • Product Specifications

    format Moving magnet type (MM type)
    output 5.0 mV (5 cm / sec)
    Frequency characteristic 20Hz-20,000Hz
    Channel separation 23dB (1Khz)
    Channel balance 1.5 dB or less
    Load resistance 47kΩ
    Load capacity 100pF
    Cantilever Aluminum alloy
    Needle tip 0.4x0.7mil Ellipse / Joined diamond
    Stylus pressure 1.3g-1.8g
    Torridge own weight 6.9g
    Dynamic Compliance 7.3×10⁻⁶㎝/dyne
  •
